5000Vrms MAX22245BAWA+ 2 Channel Reinforced Diigital Isolator 25Mbps CMTI 8-SOIC
Product Description Of MAX22245BAWA+
The MAX22245BAWA+ are a family of 2-channel reinforced, fast, low-power digital galvanic isolators using proprietary process technology. All devices feature reinforced isolation for a withstand voltage rating of 5kVRMS for 60 seconds. Both automotive and general-purpose devices are rated for operation at ambient temperatures of -40°C to +125°C.
Product Attributes Of MAX22245BAWA+
| Part Number | |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | |
| Data Rate | 25Mbps |
| Propagation Delay tpLH / tpHL (Max) | |
| Pulse Width Distortion (Max) | |
| Rise / Fall Time (Typ) | |
| Voltage - Supply | |
| Operating Temperature | |
Features Of MAX22245BAWA+
- AEC-Q100 Qualification for /V devices
- Reinforced Galvanic Isolation for Digital Signals
- 8-SOIC with 8mm of Creepage and Clearance
- Withstands 5kVRMS for 60s (VISO)
- Continuously Withstands 848VRMS (VIOWM)
- Withstands ±12.8kV Surge Between GNDA and GNDB with 1.2/50μs Waveform
- High CMTI (50kV/μs, typ)
- Low Power Consumption
- 0.78mW per Channel at 1Mbps with VDD_ = 1.8V
- 1.47mW per Channel at 1Mbps with VDD_ = 3.3V
- 3.28mW per Channel at 100Mbps with VDD_ = 1.8V
- Low Propagation Delay and Low Jitter
- Maximum Data Rate Up to 200Mbps
- Low Propagation Delay 7ns (typ) at VDD_ = 3.3V
- Clock Jitter RMS 7.5ps (typ)
- Safety Regulatory Approvals
- UL According to UL1577
- cUL According to CSA Bulletin 5A
- VDE 0884-11 Reinforced Insulation (Pending)
Applications Of MAX22245BAWA+
- Automotive
- Hybrid Electric Vehicle
- Chargers
- Battery Management Systems (BMS)
- Inverters
Simplified Application Diagram Of MAX22245BAWA+
Pin Description Of MAX22245BAWA+
Other Supply Product Types
| Part Number | Package |
| KGF1321S-R1 | SMD4L |
| SSR-220D03P | DIP-4 |
| MW6IC2240GNBR1 | TO-59 |
| SMV2020-079LF | SC-79 |
| BSP171P | SOT-223 |
| NAP-100AD | SIP |
